FTDI Industrial 8-port USB to Serial RS422 RS485 (Metal)

Short Description
USB to Octal RS-422/485 (Metal)
Sku: USB-8COMi-M
Color: BEIGE
Size: 3ft. Cable
Weight: 5
Warranty: ONE YEAR
Qty. Discount:
    Buy 12 units at $245.66 each Buy 24 units at $239.99 each
Available: In Stock Yes
Price: $ 249.78

Linux Windows 2000 Windows 7 Windows 98SE Windows ME Windows Vista Windows XP
Similar Products

    USB-4COMi-SI-M USB to Quad RS-422/485 Metal case with DIN-Rail

    More Info
    1-Port USB to RS-232 Selectable RS-422 or RS-485 Industrial Adapter

    More Info

Product Description

    USB to Octal RS-422/485 (Metal)

    USB-8COMi-M USB to Quad RS-422/485 Adapter (with Optical Isolation) USB to eight serial port converter with DB9 (9-pin male) connectors, metal housing. (RS-422/RS-485) Comes with a USB cable & power supply (120 volt, 60 hz). Features: Metal Case Optionally DIN-rail mountable with additional mounting kit. 8 RS422/485 ports Included external power supply Specifications: Number of ports: 8 Speed: Up to 921.6 Kbpz RS422/485 signals: RS422 TxD+/-, RxD+/-, RTS+/-, CTS+/-, GND RS485 Data+/-, GND Power: External power supply 5V DC required. Adapter included, 12V not possible. Drivers: Windows 98, ME, 2000, XP, 2003 Server and Vista ,Win 7 (32/64 bit) Linux (Kernel 2.4 and up built-in) Connectors: 8 DB9 Male Dimensions: 1997 x 159 x 79 mm (W??) Product includes USB-8COMi-M unit, USB cable of approximately 3 feet, Power Adapter, CD with drivers and documentation. USB-8COMi-M USB to 8 RS422/485 ports adapter Serial ports on USB allow further use of existing devices, even when the computer doesnt offer serial ports. The high speed serial port with the 128 byte FIFO allow high speed communication, even in heavy loaded systems. Unique features reduce the system load. The serial port also allows unusual speed settings like 500.000bps.

in_stockTech Notes

    USB 8 port rs-422/485 Adapter with FTDI chip

FTDI Industrial 8-port USB to Serial RS422 RS485 (Metal)
FTDI Industrial 8-port USB to Serial RS422 RS485 (Metal)
